Not Recommended for New Designs: This part is Not Recommended for New Designs (NRND).
Device/Module image

WT32I-E

Simple and High-Quality Bluetooth Audio

WT32I is not recommended for new designs.

WT32I is an audio-specific Bluetooth 3.0 module with excellent radio frequency performance and enhanced audio features, enabling a best in class Bluetooth audio experience. In addition to a certified Bluetooth radio and software stack, WT32I also contains a DSP, stereo audio codec, and battery charger making it ideal for fixed and portable audio applications. WT32I includes Bluegiga iWRAP Bluetooth stack software which implements A2DP, AVRCP v.1.5 profiles and supports aptX® and AAC audio codecs for stereo audio applications. For hands-free applications iWRAP6 software also supports HFP v.1.6, HSP, MAP and PBAP, and CVC® echo cancellation software. For data communications to Android and iOS applications, iWRAP6 also implements Bluetooth Serial Port Profile (SPP) and Apple iAP profiles. WT32I is an ideal solution for developers who want to quickly integrate the latest Bluetooth audio technologies without the time and costs typically involved with a Bluetooth audio chipset design.


Key Specs


TX Power (dBm)
+6.5
RX Sensitivity (dBm)
-90
Typical Range
Up to 200 meters
Dimensions (mm)
35.75x14.50x 2.6
TX Power (dBm)
+6.5
RX Sensitivity (dBm)
-90
Typical Range
Up to 200 meters
Dimensions (mm)
35.75x14.50x 2.6
Bluegiga Classic Legacy Modules Block Diagram
