Device/Module image

ZGM130S037HGN

Z-Wave 700 Modules

ZGM130S037HGN Z-Wave 700 Series SiP modules are fully integrated Z-Wave modules, enabling rapid development of Z-Wave solutions. A baseband controller, sub-GHz radio transceiver, crystal, decoupling and matching are included to provide a complete Z-Wave system-in-package module requiring only an external antenna. This wireless module also supports Z-Wave Long Range. The modules are an ideal solution for smart home, hospitality and MDU applications such as sensors, door locks, light switches, security networks, smart home hubs and IoT gateways.



Key Specs


Flash
512
RAM
64
Z-Wave Long Range
Yes
Sensitivity (dBm)
-103.9
Package Type
SiP
Flash
512
RAM
64
Z-Wave Long Range
Yes
Sensitivity (dBm)
-103.9
Package Type
SiP
ZGM130S Module Block Diagram

Quality Assurance, Environmental and Packaging Information

Silicon Labs targets a minimum of a 10-year lifecycle for all of its standard producs and expects to produce the ZGM130S037HGN until at least December 2029.

The longevity date shown above is for the preferred revision of this part number, for a complete list of part number revisions, use the search button below.

As part of its ongoing commitment to supply continuity, Silicon Labs may provide pin-compatible and functionally equivalent replacement products if Silicon Labs determines, at its discretion, that supply chain adjustments, product improvements, market conditions, or similar business or technical issues make this necessary or advisable.

If for business, technical or other reasons beyond Silicon Labs’ reasonable control, Silicon Labs finds that it is necessary to discontinue a product, our policy is to issue an EOL notice that provides 6 months from notice to place final orders and 12 months from notice for final shipments. This policy complies with the JEDEC standard EIA/JESD48 that is commonly used in the semiconductor industry. We provide the required support for a product for its full life cycle.

Find and download additional quality, environmental, device composition, test results, shipping and supply chain information for Silicon Labs devices.

Search results will include:

  • Product Information
  • Packing Information
  • Quality System Certifications
  • Financial Information
  • Conflict Minerals (CMRT)
  • Environmental Information
    • RoHS Certificate of Compliance
    • REACH Declaration
    • Detailed Device Composition (MDDS)
    • MCD/FMD
  • Qualification Data
  • Trade Compliance: ECC/HTS Codes
  • Supply Chain Information
  • IPC 1752-2 Class 6 (XML format)
  • ICP Test Reports
  • Halogen-Free Certificate of Compliance
  • PFOS/PFOA Certificate of Compliance
  • Supply Assurance Letter (Longevity)
