Zigbee Kits & Boards
Hardware
Mesh Networking System-on-Chip (SoC) and Modules
Select Columns
| Frequency Bands (MHz) | Flash (kB) | RAM (kB) | Output Power Range (dBm) | RX Sensitivity (dBm) | TX Current (mA) 0 dBm | RX Current (mA) | Security | GPIO | MCU Core | |
|---|---|---|---|---|---|---|---|---|---|---|
|
New
EFR32MG24 Series 2 SoCs New
EFR32MG24 Series 2 SoCs
|
2.4 GHz | 1024, 1536 | 128, 192, 256 | -20 10,19.5 | — | — | — | AES-128 AES-256 ECC SHA-1 SHA-2 Secure Enclave | 26, 28, 32 | ARM Cortex-M33 |
|
EFR32MG22 Series 2 Modules
EFR32MG22 Based Modules (Series 2)
|
2.4 GHz | 512 | 32 | -27 8 | — | — | — | AES-128 ECC SHA-1 SHA-2 | 24 | ARM Cortex-M33 |
|
EFR32MG22 Series 2 SoCs
Zigbee EFR32MG22 SoCs (Series 2)
|
2.4 GHz | 512 | 32 | -28 6 | -102.1 (250 kbit/s OQPSK) | 4.1 | 3.6 | AES-128 AES-256 ECC SHA-1 SHA-2 | 18, 26 | ARM Cortex-M33 |
|
EFR32MG21 Series 2 SoCs
Zigbee and Thread EFR32MG21 SoCs (Series 2)
|
2.4 GHz | 512, 768, 1024 | 64, 96 | -20 10,10.5,20 | -104 (250 kbps O-QPSK DSSS) | 10.4 | 9.4 | AES-128 AES-256 ECC SHA-1 SHA-2 | 20 | ARM Cortex-M33 |
|
EFR32MG21 Series 2 Modules
Zigbee and Thread EFR32MG21 Based Modules (Series 2)
|
2.4 GHz | 1024 | 96 | -20 10,12.5,20 | — | — | — | — | 20 | ARM Cortex-M33 |
|
EFR32MG12 Series 1 SoCs
Zigbee and Thread EFR32MG12 SoCs (Series 1)
|
2.4 GHz Sub-GHz | 1024 | 128, 256 | -30 10,19 | -102.7 (250 kbps O-QPSK DSSS), -120.6 dBm (2.4 kbps 2 GFSK 868 MHz) | 8.5, 9.5 | 8.4, 10.8 | AES-128 AES-256 ECC SHA-1 SHA-2 | 31, 46, 65 | ARM Cortex-M4 |
|
EFR32MG12 Series 1 Modules
Zigbee and Thread EFR32MG12 Based Modules (Series 1)
|
2.4 GHz Sub-GHz | 1024 | 256 | -30 10,17 | — | — | — | — | — | ARM Cortex-M4 |
|
EFR32MG13 Series 1 SoCs
Zigbee and Thread EFR32MG13 SoCs (Series 1)
|
2.4 GHz Sub-GHz | 512 | 64 | -30 10,19 | -102.7 (250 kbps O-QPSK DSSS) | 8.5 | 10.2 | AES-128 AES-256 ECC SHA-1 SHA-2 | 16, 31 | ARM Cortex-M4 |
|
EFR32MG13 Series 1 Modules
Zigbee and Thread EFR32MG13 Based Modules (Series 1)
|
512 | 64 | -30 10,19 | — | — | — | — | — | ARM Cortex-M4 | |
|
EM359x Wireless Zigbee SoCs
Zigbee SoCs
|
512 | 64 | -55 8 | -102 (boost) | 31 | 26.5 | AES-128 | 0 | ARM Cortex-M3 | |
|
EM358x Wireless Zigbee SoCs
Zigbee SoCs
|
256, 512 | 32, 64 | -55 8 | -102 (boost) | 31 | 26.5 | AES-128 | 0 | ARM Cortex-M3 | |
|
EM35x Wireless Zigbee SoCs
Zigbee SoCs
|
128, 192 | 12 | -55 8 | -102 (boost) | 31 | 26.5 | AES-128 | 0 | ARM Cortex-M3 |
Sort A -> Z
Sort Z -> A
Filter by values...
Find the Right Zigbee Device for your Use Case
EFR32xG24 Pro Kit +10 dBm
The EFR32xG24 +10 dBm Pro Kit is designed to support the development of wireless IoT devices based on the EFR32xG24 and support the development of 2.4 GHz wireless protocols including BLE, Bluetooth mesh, Zigbee, Thread, and Matter.
EFR32xG24 Pro Kit +10 dBm
The EFR32xG24 +10 dBm Pro Kit is designed to support the development of wireless IoT devices based on the EFR32xG24 and support the development of 2.4 GHz wireless protocols including BLE, Bluetooth mesh, Zigbee, Thread, and Matter.
EFR32xG24 Pro Kit +20 dBm
The EFR32xG24 +20 dBm Pro Kit is designed to support the development of wireless IoT devices based on the EFR32xG24 and support the development of 2.4 GHz wireless protocols including BLE, Bluetooth mesh, Zigbee, Thread and Matter.
EFR32xG24 Pro Kit +20 dBm
The EFR32xG24 +20 dBm Pro Kit is designed to support the development of wireless IoT devices based on the EFR32xG24 and support the development of 2.4 GHz wireless protocols including BLE, Bluetooth mesh, Zigbee, Thread and Matter.
EFR32xG24 Dev Kit
The EFR32xG24 Dev Kit is a compact, feature-packed development platform. It provides the fastest path to develop and prototype wireless IoT products. The development platform supports up to +10 dBm output power and includes support for the 20-bit ADC as well as other key features.
EFR32xG24 Dev Kit
The EFR32xG24 Dev Kit is a compact, feature-packed development platform. It provides the fastest path to develop and prototype wireless IoT products. The development platform supports up to +10 dBm output power and includes support for the 20-bit ADC as well as other key features.
Thunderboard Sense 2 Sensor-to-Cloud Advanced IoT Kit
Thunderboard Sense 2 is a compact development platform, featuring a range of sensors, allowing rapid prototyping of Bluetooth, Thread, and Zigbee IoT products.
Thunderboard Sense 2 Sensor-to-Cloud Advanced IoT Kit
Thunderboard Sense 2 is a compact development platform, featuring a range of sensors, allowing rapid prototyping of Bluetooth, Thread, and Zigbee IoT products.
Pro Kit Mainboard Accessory Kit
The accessory kit enables the use of the Pro Kit Mainboard (BRD4002A) as a stand-alone debug adapter for custom hardware. It includes a mini-simplicity 10-pin flat cable which provides AEM (energy monitoring), SWD interface, VCOM (UART bridge) and PTI (Packet Trace Interface) support. Additionally it also includes the necessary wire harness and hooks for the on-board logic analyzer.
Pro Kit Mainboard Accessory Kit
The accessory kit enables the use of the Pro Kit Mainboard (BRD4002A) as a stand-alone debug adapter for custom hardware. It includes a mini-simplicity 10-pin flat cable which provides AEM (energy monitoring), SWD interface, VCOM (UART bridge) and PTI (Packet Trace Interface) support. Additionally it also includes the necessary wire harness and hooks for the on-board logic analyzer.
EFR32xG24 Wireless 2.4 GHz +20 dBm Antenna Diversity Radio Board
The EFR32xG24 +20 dBm Antenna Diversity Radio Board is designed work with the WSTK main board (not included) to support the development of wireless IoT devices based on 2.4 GHz 802.15.4 protocols including OpenThread and Zigbee.
EFR32xG24 Wireless 2.4 GHz +20 dBm Antenna Diversity Radio Board
The EFR32xG24 +20 dBm Antenna Diversity Radio Board is designed work with the WSTK main board (not included) to support the development of wireless IoT devices based on 2.4 GHz 802.15.4 protocols including OpenThread and Zigbee.
EFR32xG24 Wireless 2.4 GHz +20 dBm Radio Board
The EFR32xG24 +20 dBm Radio Board is designed work with the WSTK main board (not included) to support the development of wireless IoT devices based on 2.4 GHz wireless protocols inlcuding BLE, Bluetooth mesh, Zigbee, Thread, and Matter.
EFR32xG24 Wireless 2.4 GHz +20 dBm Radio Board
The EFR32xG24 +20 dBm Radio Board is designed work with the WSTK main board (not included) to support the development of wireless IoT devices based on 2.4 GHz wireless protocols inlcuding BLE, Bluetooth mesh, Zigbee, Thread, and Matter.
EFR32xG24 Wireless 2.4 GHz +10 dBm Radio Board
The EFR32xG24 +10 dBm Radio Board is designed work with the WSTK main board (not included) to support the development of wireless IoT devices based on 2.4 GHz wireless protocols inlcuding BLE, Bluetooth mesh, Zigbee, Thread, and Matter.
EFR32xG24 Wireless 2.4 GHz +10 dBm Radio Board
The EFR32xG24 +10 dBm Radio Board is designed work with the WSTK main board (not included) to support the development of wireless IoT devices based on 2.4 GHz wireless protocols inlcuding BLE, Bluetooth mesh, Zigbee, Thread, and Matter.
Kits and Boards
Zigbee Kits & Boards
Please Note: The following kits are the only ones that grants access to the EmberZNet SDK:
- EM35X-DEV
- EM35X-DEV-IAR
- RF4CE-DEV
- SIP-KITSZG001
- SLWSTK6000A
- SLWSTK6000A
- SLWSTK6000B
- SLWSTK6001A
- SLWSTK6002A
- SLWSTK6003A
- SLWSTK6005A
- SLWSTK6006A
- SLWSTK6102A
- SLWSTK6021A
- SLWSTK6104A
- SLWSTK6050A
EFR32xG21 Wireless Gecko Starter Kit
The EFR32xG21 Wireless Gecko Starter Kit (SLWSTK6006A) includes everything needed to enable developers to create a mesh network and evaluate the EFR32xG21A with Secure Element and the EFR32xG21B with Secure Vault Series 2 Wireless Gecko SoCs. This kit provides the common baseboard and comes with 6 xG21A modules (SLWRB418xA). If you want to evaluate the EFR32xG21B you must buy the xG21B modules (SLWRB4181C +10 dBm) separately.
EFR32xG21 Wireless Gecko Starter Kit
The EFR32xG21 Wireless Gecko Starter Kit (SLWSTK6006A) includes everything needed to enable developers to create a mesh network and evaluate the EFR32xG21A with Secure Element and the EFR32xG21B with Secure Vault Series 2 Wireless Gecko SoCs. This kit provides the common baseboard and comes with 6 xG21A modules (SLWRB418xA). If you want to evaluate the EFR32xG21B you must buy the xG21B modules (SLWRB4181C +10 dBm) separately.
Software and Tools
Zigbee Software Development
Silicon Labs Zigbee software includes industry-leading software stacks and development tools for Zigbee applications. In conjunction with modules, SoCs and reference designs for Zigbee from Silicon Labs, developers can use software and tools from Silicon Labs to quickly and reliably:
- Develop multi-node mesh networks
- Monitor and debug multiple nodes simultaneously
- Visually analyze system performance
| Zigbee SDK | Silicon Labs EmberZNet PRO Zigbee networking protocol stack is a complete Zigbee protocol software package containing all the elements required for robust and reliable mesh networking applications on Silicon Labs' Ember platforms. The Zigbee stack provides "professional grade" networking for the most challenging applications such as Smart Energy / Advanced Metering Infrastructure (AMI), Home Automation, Home Security, Smart Lighting and Building Automation systems. | |
| Unify SDK | Unify SDK simplifies IoT infrastructure development including gateways, access points, hubs, bridges, and application processor-based end products. Unify SDK provides common building blocks that ease connectivity across IoT ecosystems including Zigbee. |
Resources
Zigbee Technical Library
Access to Data Sheets, App Notes, and more.
Zigbee Training
Find all Zigbee training resources
Zigbee API Documentation
Find all Zigbee API documentation
Learn About Zigbee
overview
What is Zigbee?
Silicon Labs is the vendor of choice for OEMs developing Zigbee networking into their products. The Silicon Labs 802.15.4 platform is the most integrated, complete and feature rich solution available for Zigbee — a family of Wireless SoCs, based on Arm® Cortex® processor and 2.4 GHz transceiver, together the most reliable, scalable and advanced software and supported by best-in-class development tools.
