WF200S

The Perfect Wi-Fi Transceiver IC for IoT Applications

The WF200S is the perfect Wi-Fi transceiver for your secure, low-power IoT Wi-Fi needs. The Wi-Fi transceiver contains a 2.4 GHz 802.11 b/g/n radio (MAC and PHY layer), optimized for low power and optimal RF performance in crowded RF environments. The device supports both Linux-based hosts and RTOS-based hosts to deliver a complete Wi-Fi solution. High speed SPI and SDIO host interfaces provide flexibility and throughput. The WF200S uses a secure link interface between the host and the transceiver.


Key Specs


Secure Link
Yes
Protocol
2.4 GHz 802.11 b/g/n
TX Power Max (dBm)
17
RX Sensitivity (dBm)
-96.3
Associated Sleep (uA)
22
Serial Interface
SDIO, SPI
Onboard Stack
No
Package Size (mm)
4x4
Secure Link
Yes
Protocol
2.4 GHz 802.11 b/g/n
TX Power Max (dBm)
17
RX Sensitivity (dBm)
-96.3
Associated Sleep (uA)
22
Serial Interface
SDIO, SPI
Onboard Stack
No
Package Size (mm)
4x4
WF200 Block Diagram
