Bluetooth Module, Chip, and Software Solutions for Bluetooth Low Energy

The EFR32BG26 Bluetooth SoCs are ideal for IoT wireless connectivity using Bluetooth Low Energy and Bluetooth mesh for smart home, lighting, and portable medical products. With key features like high-performance 2.4 GHz RF, low current consumption, an AI/ML hardware accelerator, and Secure Vault™, IoT device makers can create the smart, robust, and energy-efficient products that are secure from remote and local cyber-attacks. An ARM Cortex®-M33 running up to 78 MHz and up to 3200 kB of flash and 512 kB of RAM provides resources for demanding applications while leaving room for future growth. Target applications include gateways/hubs, sensors, switches, smart plugs, LED lighting, and luminaires.

The EFR32BG24 Wireless SoCs are ideal for IOT wireless connectivity using Bluetooth Low Energy and Bluetooth mesh for smart home, lighting, and portable medical products. With AECQ-100 qualification, support for Channel Sounding, and key features like high performance 2.4 GHz RF, low current consumption, an AI/ML hardware accelerator and Secure Vault™, IoT device makers can create the smart, robust, and energy-efficient products that are secure from remote and local cyber-attacks. An ARM Cortex®-M33 running up to 78 MHz and up to 1.5 MB of Flash and 256 kB of RAM provides resources for demanding applications while leaving room for future growth. Target applications include gateways/hubs, sensors, switches, door locks, smart plugs, LED lighting, luminaires, blood glucose meters and pulse oximeters.

The BG24L, optimized for Channel Sounding and Bluetooth LE applications, features a built-in AI/ML hardware accelerator that offers up to 8x faster inferencing over Cortex-M, and consumes up to 6x lower power making it ideal for cost-effective intelligent edge nodes with a long battery life. The device prioritizes security with Secure Vault Mid, safeguarding against remote attacks. The pin-compatibility of this SoC with other device families in the Silicon Labs Bluetooth portfolio allows customers to seamlessly migrate to SoCs with expanded memory, higher clock speeds, and additional security. BG24L is an ideal fit for channel sounding-related applications like Asset Tracking and Direction Finding as well as AI/ML-related applications such as Predictive Maintenance.

The BG22L Bluetooth low energy solution is a cost-effective SoC designed for connectionless applications. It utilizes low power RF technology and Secure Vault™ Mid to deliver exceptional battery life and robust security, allowing connectionless tags to function seamlessly for up to 10 years on a single coin cell battery. The pin-compatibility of this SoC with other device families in the Silicon Labs Bluetooth portfolio allows customers to seamlessly migrate to SoCs with expanded memory, higher clock speeds, and extended temperature range. Ideal for various applications, the BG22L provides efficiency and reliability, making it suitable for Bluetooth mesh low-power nodes, asset tracking tags, and personal healthcare devices.

EFR32BG22 and EFR32BG22E Bluetooth low energy (LE) wireless SoC solutions are part of the Wireless Gecko Series 2 platform. These devices are designed with a strong focus on energy efficiency, offering best-in-class ultra-low transmit and receive power, and a high-performance, low-power Arm® Cortex®-M33 core delivers industry-leading energy efficiency that can extend coin cell battery life up to ten years. Where BG22 allows you to create energy-efficient applications, the BG22E – ‘E’ denoting Energy Conservation – takes this a step further by enhancing battery longevity and supporting designs that eliminate the need for batteries altogether. Our BG22 and BG22E family's are the ideal market leading SoCs for Ambient IoT or Energy Harvesting devices. Target applications include Bluetooth mesh low-power nodes, smart door locks, personal healthcare and fitness devices. Asset tracking tags, beacons and indoor navigation also benefit from the SoCs' versatile Bluetooth Angle of Arrival (AoA) and Angle of Departure (AoD) capabilities and sub-one-meter location accuracy.

The EFR32BG27 family of wireless SoCs opens up new possibilities by offering an ultra-small WLCSP package (2.3 mm x 2.6 mm) capable of running on button cell batteries. Now device makers can address applications with extremely small form-factor requirements without sacrificing performance and security. The BG27 Bluetooth SoC features an integrated DCDC boost that allows operation down to 0.8 volts, enabling support for single-cell alkaline and 1.5-volt button cell batteries that are typically used in medical applications for battery-operated patches and continuous glucose monitoring (CGM) devices. Additionally, the wakeup pin on the BG27 allows products in a warehouse or transit to remain off for months, consuming less than 20 nA, ensuring the battery remains fully charged for use. The integrated coulomb counter enables accurate battery level monitoring to avoid unexpected battery depletion for critical applications. Target applications include connected medical devices, wearables, sensors, switches, smart locks, and both commercial and LED lighting.

Wireless Gecko Series 2 devices are the next evolution of Wireless Gecko devices bringing high performance, low power, and secure solutions to the Internet of Things. Designed to increase processing capability, improve RF performance and lower active current, the devices also provide the highest level of IoT device security. The EFR32BG21 devices are also designed to support Silicon Labs' enhanced security option, Secure Vault. Learn more about Silicon Labs' security portfolio.

EFR32BG21 devices are 2.4 GHz wireless SOCs optimized for line-powered Bluetooth Low Energy and Bluetooth mesh applications, including connected lighting, smart plugs, gateways and voice assistants. An 80 MHz ARM® Cortex®-M33 core provides plenty of processing capability while an integrated security subsystem provides leading security features that greatly reduce the risk of IoT security breaches and compromised intellectual property. With better than -104.3 dBm sensitivity and up to +20 dBm output power, the EFR32BG21 family uses Simplicity Studio 5 development tools, providing easy migration and fast time-to-market with development kits, SDKs, mobile apps, our energy profiler and patented network analyzer.

BGM260P is a family of certified 2.4 GHz wireless modules optimized for battery-powered IoT devices. Based on the EFR32BG26 SoCs, the modules support Bluetooth Low Energy and Bluetooth mesh, delivering exceptional RF performance, energy efficiency, and industry-leading security with Secure Vault® technology. The BGM260P modules provide global regulatory certifications and support advanced development and debugging tools that simplify development and speed time to market.

BGM240 is a family of certified 2.4 GHz wireless modules optimized for battery-powered IoT devices. Based on the EFR32BG24 SoCs, the modules support Bluetooth Low Energy and Bluetooth mesh, delivering exceptional RF performance, energy efficiency and industry-leading security with Secure Vault® technology. The BGM240 modules provide global regulatory certifications and support advanced development and debugging tools that simplify development and speeds time to market.

BGM220 Bluetooth® modules are designed and built to meet the performance, security, and reliability requirements of battery-powered IoT products. Based on the EFR32BG22 SoC, BGM220 is a full solution that comes with fully upgradeable, robust software stacks, world-wide regulatory certifications, advanced development and debugging tools, and support to help accelerate time-to-market. Available in multiple packages, PCB or ultra-compact SiP, BGM220 is ideal for a broad range of Bluetooth LE applications including asset tags, beacons, portable medical, fitness, and Bluetooth mesh low power nodes.

BGM210P Bluetooth modules feature an optimized form factor with integrated chip antenna and low profile for space-constrained IoT designs, including smart lighting, HVAC, building and factory automation systems. BGM210PB modules support Silicon Labs' enhanced security option, Secure Vault. Learn more about Silicon Labs' security portfolio.

BGM210L Bluetooth lighting modules combine a custom form factor to ease mounting inside LED bulb housings and PCB trace antennas to maximize wireless range, high temperature ratings, extensive global regulatory certifications and low active power consumption, delivering the perfect wireless solution for cost-sensitive, high-volume smart LED lightbulbs.
